The second accessory required is a Multifunction Cable, such as the 0.5, 1, 2, 5, or 10 m SHC68-68-EPM Shielded Cable, 68-D-Type to 68 VHDCI Offset, the 1 or 2 m SHC68-68, Twisted Pair Cable with Basic Shielding, or the.
#2 ao 16 dio 2 counter 1 trigger series#
Question: Which accessories are required to operate the PCIe-6321 X Series DAQ?Īnswer: To operate the PCIe-6321 X Series DAQ, the user first needs an I/O connector, such as the SCB-68A Noise Rejecting, Shielded I/O Connector Block, the CB-68LP Unshielded I/O Connector Block, the BNC-2110 Noise Rejecting, Shielded BNC Connector Block, the CB-68LPR I/O Connector Block, the TBX-68, 68-pin Screw Terminal Connector Block, or the BNC-2090A Rack-mountable Accessory for 68-pin Multifunction DAQ. National Instruments PCIe-6321 Frequently Asked Questions Call or email us today for more information about calibrating the PCIe-6321! When you order the PCIe-6321 with us, you can request basic (unaccredited) in-house calibration that will calibrate the part to the manufacturer specifications prior to being shipped. We offer high-quality NIST accredited calibrations through a 3rd party, with an average turnaround time of 1 to 2 weeks. If you need the PCIe-6321 calibrated, Apex Waves provides options. While the recommended calibration period for individual parts varies, most parts should be calibrated either annually or every two years to ensure accuracy. The PCIe-6321 is available to be calibrated. This will help modify the self-calibration constants to make up for any errors as a result of temporary variations in the atmosphere. National Instruments suggests calibrating the NI PCIe-6321 device when the ambient temperature is altered and after installation. This model comes equipped with several digital waveform generations and waveform acquisition functions, such as a start/pause trigger, sample clock, reference trigger, and a sample clock timebase.
The National Instruments PCIe-6321 X Series Device supports external digital triggers through any PFI and RTSI source. The PCIe-6321 has a digital I/O with 24 channels in total, and has 8 DMA channels which can be used for analog input, analog output, digital input, digital output, counter/timer 0, counter/timer 1, counter/timer 2, counter/timer 3. The device has an analog input with 16 single ended/8 differential channels, and an analog input with 2 channels. The device has an operational temperature range of 0 ☌ to 50 ☌. These counters operate with 0 to 25 MHz external base clock frequency at 50 ppm base clock accuracy. The four general purpose counters can be utilized for various counter and position measurements, such as two-pulse encoding, edge counting, pulse width, period, semi-period, two-edge separation, and more. On a single analog channel or multiple channels, the PCIe-6321 NI can acquire samples at a rate of 250 kS/s.
With the NI-DAQmx configuration utility and driver, the user can configure their NI PCIe-6321 quickly. This Multifunction I/O Device is well suited for a variety of applications, including but not limited to, basic data logging, test automation, and control automation. The integrated NI-STC3 synchronization and timing technology makes this device capable of providing advance level timing functionality, including re-triggerable measurement tasks and digital and analog timing engines.
#2 ao 16 dio 2 counter 1 trigger software#
With the help of the high-throughput PCI Express bus, the PCIe-6321 X Series DAQ delivers high-performance functionality and a multicore-optimized application software and driver. This model offers analog and digital I/O, as well as four 32-bit timers for PWM, frequency, encoder, event counting, etc. The PCIe-6321 (Part Number: 781044-01) is a 16 AI, 2 AO, 24 DIO PCI Express based Multifunction I/O Device from the X Series by National Instruments. National Instruments PCIe-6321 Multifunction I/O Device
